    Fuel Electric Polarization Control Furnace Cabinet Parts Customized

    Ask Lasest Price
    Brand Name : Chitherm
    Price : Negotiable
    Delivery Time : Customized
    Payment Terms : Customized
    Supply Ability : 50 Sets/Year
    Model Number : 7 passageway
    Certification : ISO
    • Product Details
    • Company Profile

    Fuel Electric Polarization Control Furnace Cabinet Parts Customized

    Fuel Electric Polarization Control Furnace Cabinet Parts Customized
    AttributeValue
    Surface TreatmentPainted
    FuelElectric
    Range of ApplicationsIndustrial
    Transport PackageWooden Packaging
    Specification800*1850*500mm(W*H*D)
    TrademarkChitherm
    OriginChina
    HS Code8514101000
    Supply Ability50 Sets/Year
    CustomizationAvailable
    CertificationISO
    CustomizedCustomized
    Product Description

    Customized Electric Chitherm Polarization Control Cabinet Fuel Electric for Optimal Performance

    1. Basic Configuration
    • Temperature control channels: 5 + 2, of which 5 channels are used to control the sintering furnace, and the remaining 2 channels are spare.
    • Temperature control instrument: Eurotherm3504.
    • Number of instruments: Each control cabinet is equipped with 7 temperature controllers.
    • External dimensions: 800*1850*500mm(W*H*D).
    • Appearance Color: Light gray.
    Chitherm Polarization Control Cabinet showing temperature control interface
    2. Control System
    • Control instrument: Controlled by Eurotherm3504 intelligent regulator, it has multiple alarm protection functions such as PID parameter self-tuning, high temperature upper limit alarm, thermocouple failure indication, etc.
    • Control mode: power adjustment and voltage control.
    • Over-temperature treatment: When the temperature over-temperature phenomenon occurs, the temperature over-temperature alarm system will immediately send a sound and light alarm signal and cut off the heating at the same time.
    Chitherm Polarization Control Cabinet showing control panel and wiring
    3. Delivery List
    NameMain contentQty.
    Control cabinet1 SET
    Temperature controllerEurotherm35041 SET
    Power regulator1 SET
    Low-voltage appliances1 SET
    Touch Screen1 SET
